High-Hardness, High-Precision Mold Manufacturing
- We possess high-precision machining technology capable of processing high-hardness materials of HRC 60 or higher at micrometer-level accuracy.
- Our experience includes mold manufacturing for vibration-damping rubber, sealing components (O-rings), die casting, and fuel cell stack gaskets.
- Equipped with advanced precision facilities—including 40,000 rpm high-speed machining centers, precision wire EDM machines, and 3D laser marking systems—we maintain in-house capabilities for key manufacturing processes.
- Through 24-hour operation, we ensure the shortest possible delivery times.
Mold R&D Capabilities
| 3D Modeling / CAM | CAE (Simulation) |
|---|---|
|
CAMTOOL, UG, Veri-cut, GIBBS
|
AnyCasting (Casting / Die Casting)
|
NVH (noise, vibration, harshness)
Precision rubber mold manufacturing for the production of automotive anti-vibration rubber components.
- Compatible with rotary injection molding machines of 800, 2000, and 4000 cc capacity
- Mold manufacturing for a wide range of sizes from small to large, with multi-cavity structures to improve production efficiency
- Optimized runner structure design to balance rubber flow and minimize quality variation between products
SEALING / Fuel Cell Gasket
High-precision molds for rubber-molded products designed to prevent leakage and maintain airtightness.
- Gasket molds use high-speed precision machining (over 30,000 rpm) with Ø0.1 mm micro-tools
- Circular core sealing molds are machined using combined lathe and milling machines to ensure concentricity and roundness
CRB (cold runner block)
Continuous injection mold block (CRB) that distributes molten rubber to multiple cavities (product shape spaces) while maintaining runner temperature to prevent premature curing of the material.
- Temperature control technology with optimized nozzle and cooling channel design for multi-cavity molds
- Analysis of rubber runner structure to minimize injection balance variation for each nozzle
- Optimized injection nozzle design to reduce curing time
Die Casting
Die casting molds for shaping molten metal (aluminum) into desired product forms under high pressure.
- Structural design optimized for casting, considering gas venting and cooling efficiency
- Parting line design and structure tailored to product characteristics to minimize post-processing
- Use of high-durability core materials with heat treatment and coating to ensure wear resistance
High-performance precision machining centers are essential for manufacturing high-precision molds. PhyugHwa ENG is equipped with advanced precision machining equipment to provide customers with superior-quality molds.
MAKINO , IQ500
- Ultra-precision high-speed machining center with 45,000 rpm spindle
- Linear motor system for precise dimensional machining
- Special cooling structure to prevent spindle thermal displacement during long operations
- Tool measurement via vision system
- Suitable for molds requiring mirror-finish machining, such as LED and optical components
Table size: 750 x 500 mm, HSK-E2 spindle
MAKINO , V33I
- High-precision high-speed machining center with 30,000 rpm spindle
- Cooling system to prevent ball screw displacement during movement
- Special cooling structure to prevent spindle thermal displacement during long operations
- Optimized for machining high-hardness precision molds
Table size: 650 x 500 mm, HSK-F63 spindle
SODICK, AL600P
- Ultra-precision wire EDM (Electrical Discharge Machine)
- Linear motor system for precise dimensional machining
- Thermal displacement compensation to counteract environmental temperature changes
- 4-axis (X, Y, Z, U) for complex shape machining
Maximum machining area: 800 x 570 mm
SODICK, AL60G
- Ultra-precision contour EDM (Electrical Discharge Machine)
- Linear motor system for precise dimensional machining
- High-speed machining enabled by high-power motor
- Equipped with the latest ArcRes 4-circuit EDM technology
- Minimizes electrode wear and ensures mirror-finish discharge quality
Stroke: 600 x 400 mm, maximum workpiece weight: 1.5 t
YAMAZAKI MAZAK , FH-10800
- Optimal Machining Center for Mold Base Processing
- Unattended continuous machining of up to 24 workpieces using dual 12-pallet system
- Robust, rigid structure for enhanced machining precision
- Capabilities
-
- Machinable workpiece size up to 1,000 × 1,000 mm
- Spindle speed: 7,000 rpm
YAMAZAKI MAZAK ,
QT250 / QT250MY
- High-Precision CNC Lathe
- Built-in motor spindle and high-rigidity machine structure for superior precision
- Gearless and beltless design minimizes vibration and runout, ensuring high surface accuracy
- Machining Capacity
- Machining Capacity
-
- Maximum workpiece diameter: Ø250 mm
Accurate measurement is essential to ensure the quality of high-precision machined components. To achieve flawless quality, we operate a wide range of optimized inspection and calibration equipment.
3D Coordinate Measuring Machine
To ensure the quality of high-precision molds and automation equipment components, PhyungHwa has implemented 3D coordinate measuring machines (CMMs) for precise measurement and quality verification.
A CMM accurately measures product dimensions, shapes, positions, and tolerances, allowing comparison between design data and the actual product to confirm dimensional accuracy. This minimizes errors in the production process and helps maintain consistent product quality.
Through advanced measurement equipment and a systematic quality management system, PhyungHwa reliably delivers high-quality products that meet customer requirements. We continuously pursue quality improvement to be a trusted manufacturing partner.
Form and Surface Roughness Measurement System
To ensure precise quality control, PhyungHwa has implemented advanced measurement equipment to systematically manage product geometry and surface conditions. By utilizing form measuring instruments and surface roughness testers, we verify both the dimensional accuracy and surface quality of machined components, ensuring consistent and reliable product performance.
- Key Measurement Parameters of Form Measuring Instruments
-
- Straightness
- Roundness
- Concentricity and Coaxiality
- Cross-sectional Profile
- Angular and Curvature Geometry
Image Dimension Measurement System
To achieve precise and rapid quality inspection, PhyungHwa has implemented a one-touch image dimension measuring system for inspecting product dimensions, particularly for high-precision sealing molds and small mechanical components.
Based on high-resolution imaging technology, this system allows components to be placed on the stage and automatically measures multiple dimensions simultaneously at the push of a button, providing a high-speed, high-precision inspection solution.
Plating Thickness Measurement System
To precisely manage mold surface quality and plating conditions, PhyungHwa has implemented a plating thickness measurement system to inspect plating uniformity and thickness.
This system employs X-ray-based non-destructive analysis technology, providing rapid and accurate measurement of plating thickness and metal composition, ensuring precise quality control.
