The R&D Center leads new technological development with advanced equipment including the 4 post road simulator.
NVH Instrument
| 구분 | 내용 |
|---|---|
| Equipment Classification | NVH Evaluator |
| Equipment Name | Actual vehicle hemi-anechoic room and the 4 WD chassis dynamometer |
| Equipment Picture |  |
| Overview | It is composed of the 4-wheel drive chassis dynamometer in the actual vehicle hemi-anechoic room (background noise 18dB). It is a vehicle driving evaluator that reproduces actual road driving conditions of the vehicle in the anechoic room. |
| Application |
- Interior Noise & Vibration at Run Up/Down - Idle Noise & Vibration - Mount Isolation - Dynamic Damper Tuning - Transfer Path Analysis - Modal Analysis & ODS - Torsional Vibration for Damper Pulley/Shaft |
| 구분 | 내용 |
|---|---|
| Equipment Classification | NVH Evaluator |
| Equipment Name | 4 Post Road Simulator |
| Equipment Picture |  |
| Overview | The 4 post road simulator is the vertical vehicle excitation evaluator which uses the actuator to simulate the sinusoidal and random waves and actual vertical road motions. |
| Application |
NVH
- Hydro. Engine Mount Tuning - Rigid Body Mode Analysis - Wheel Hop Test - ODS - Mass Damper Tuning Simulation - Road Profile Reproduction - Durability Test - SBR Test (joint) |
Reliability Instrument
| 구분 | 내용 |
|---|---|
| Equipment Classification | Simulator |
| Equipment Name | MAST(Multi Axial Simulation Table) |
| Equipment Picture |  |
| Overview | The MAST simulator reproduces the actual vehicle RLD (road load data) and evaluates complex vibratory durability of the engine mount and various parts. |
